AS/NZS 5532



Test or certification item 测试或认证名称:  Manufacturing requirements for single-point anchor device used for harness-based work at height
固定式和便携式单点锚定装置的制造性能要求、试验方法以及标记、标签和包装要求，用于保护人员在工业环境中防止坠落、工作定位和行程限制（约束技术）时从高处坠落



Test or certification info 测试和认证相关内容:

锚固测试

每个单点锚必须在锚和结构性能良好的情况下进行这四项测试，然后才能声称符合AS/NZS 5532标准。

Every single point anchor must have these four tests conducted with both the anchor and the structure performing satisfactorily before they can claim to conform to the AS/NZS 5532 Standard.

测试1：与屋顶板一致的动载荷-15kN

该试验要求将100kg的质量从锚上掉下来2米，同时将其安装在拟安装的基底/屋顶甲板上。该试验与甲板一起进行。

Test 1: Dynamic load in-line with the roof sheet - 15kN

This test requires a 100kg mass to be dropped 2 metres off the anchor while it is installed on the substrate / roof deck that it is intended to be installed on. The test is performed in-line with the deck.

测试2：与屋顶板一致的静载荷-15kN

锚将1530kg（15kN）的荷载保持3分钟。必须再次将锚安装在相关基底/屋顶板上。

Test 2: Static load in-line with the roof sheet - 15kN

A load of 1,530kg (15kN) is held by the anchor for a period of 3 minutes. Once again the anchor must be installed onto the relevant substrate / roof deck.

测试3：穿过屋顶板的动载荷-15kN

第三次试验与试验1相同，但不是将锚与基底/屋顶板串联加载，而是将其旋转90度以加载。

Test 3: Dynamic load across the roof sheet - 15kN

This third test is the same as Test 1, however instead of the anchor being loaded in-line with the substrate / roof deck it is turned 90 degrees to be loaded across.

测试4：穿过屋顶板的静载荷-15kN

第四次试验与试验2相同，但在锚穿过基底/屋顶板的情况下进行。

Test 4: Static load across the roof sheet - 15kN

The fourth test is the same as Test 2 but is performed with the anchor being loaded across the substrate / roof deck.



Norm refer 涉及法规: PPE 个人防护用品



Refer products 涉及产品:



Lead time 周期:  常规服务 regular service 15 工作日 working days （ URGENT service, to be confirm, 加急服务待定 ）



Sample size 送样规格:   8pcs finished products 八个成品



Photo for reference 涉及图片:



Sample report 样本报告：
