EN 14877返回 Back
| 主标准 |
Clause 条款 |
Test Item 测试项目 |
Test Method 测试方法 |
Sample Requirement 样品要求 |
Test time(WD) 测试周期(工作日) |
Remark 备注 |
|
EN 14877:2013 室外运动场用合成表面规范 Synthetic surfaces for outdoor sports areas-Specification |
EN 14877 2.1.1 | Friction | EN 13036-4 | >500mm*300mm | 7 | dry and wet |
| EN 14877 2.1.2 | Shock absorption | EN 14808 |
A,C 等级 3.5mx3.5m P,M 等级 1.0mx1.0m |
20 | 3 temperatures (10°C,23°C,40° C) | |
| EN 14877 2.1.3 | Vertical deformation | EN 14809 |
A,C 等级 3.5mx3.5m P,M 等级 1.0mx1.0m |
20 | 3 temperatures (10°C,23°C,40° C) | |
| EN 14877 2.1.4 | Vertical ball behaviour | EN 12235 | 2mx2m | 15 | Basketball only | |
| EN 14877 2.2.1 | Water permeability | EN 12616 | 500mm*500mm | 15 | ||
| EN 14877 2.2.2 | Resistance to wear | ISO 5470-1 | 115*115mm, 6 pcs | 10 | 1000 cycles | |
| EN 14877 | Resistance to temperature, water and UV light | EN 14836 | 125 | 3000h UV cycles, after weathering, do tensile, resistance to wear, spike resistance, shock absorption | ||
| EN 14877 2.2.4 | Tensile properties | EN 12230 | 200mm*100mm, 3pcs/direction | 10 | ||
| EN 14877 2.2.5 | Thickness | EN 1969 | ||||
| EN 14877 | Spike resistance | EN 14810 | 180mm*220mm, 5pcs/direction | 20 |
